Troubleshooting
132 Service Instructions 867 - 04.0 - 10/2019
25.2.2 Error Messages
.
7801 Software version error
(DAC classic only; only the
functions of the DAC basic
will remain available)
Software update
Replace control
7802 Software update error (DAC
classic only; only the
functions of the DAC basic
will remain available)
Software update
Replace control
7803 Communication error (DAC
classic only; only the
functions of the DAC basic
will remain available)
Restart of the control
Software update
Replace control
Code Type Meaning Remedial action
1000 Error Sewing motor encoder plug
(Sub-D, 9-pin) not connected
Connect encoder cable to
the control, use correct
connection
1001 Error Sewing motor error:
Sewing motor plug (AMP) not
connected
Check connection and
plug in, if necessary
Test sewing motor phases
(R= 2.8 Ω, high
impedance to PE)
Replace encoder
Replace sewing motor
Replace control
1002 Error Sewing motor insulation fault Check sewing motor
phase and PE for low-
impedance connection
Replace encoder
Replace sewing motor
1004 Error Sewing motor error:
Incorrect sewing motor
direction of rotation
Replace encoder
Check plug assignment
and change, if necessary
Check wiring in machine
distributor and change it, if
necessary
Test sewing motor phases
and check for correct
value
1005 Error Sewing motor blocked Eliminate stiff movement
in the machine
Replace encoder
Replace sewing motor
Code Type Remedial action
