Working basis

Service Instructions 867 - 04.0 - 10/2019 17

3.3.4 Assembling and disassembling the valve cover

Fig. 4: Assembling and disassembling the valve cover

Disassembling the valve cover

To disassemble the valve cover:

1. Loosen the screws (1).

2. Disassemble the valve cover (2).

Important

Make sure not to tear off any cables.

Assembling the valve cover

To assemble the valve cover:

1. Assemble the valve cover (2).

2. Tighten the screws (1).

Important

Make sure not to pinch any cables.

(1) - Screws (2) - Valve cover

②

①

Default Chapter3
