DURKOPP ADLER 867 Service Manual

Working basis
14 Service Instructions 867 - 04.0 - 10/2019
3.3 Removing the covers
For many types of adjustment work, you will have to remove the machine
covers first in order to access the components.
This chapter describes how to remove and then assemble the individual
covers again. The text for each type of adjustment work then specifies only
the cover that needs to be removed at that particular time.
3.3.1 Tilting the machine head
In order to access the components on the underside of the machine, you
must first tilt the machine head.
Fig. 1: Tilting the machine head
Tilting the machine head
To tilt the machine head:
1. Tilt the machine head as far as it will go.
Erecting the machine head
To erect the machine head:
1. Erect the machine head.
Risk of injury!
Crushing injuries from moving parts.
Switch off the machine before you remove the
covers or refit them.
WARNING

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
