7.Selectmenu6Configuration–3Cooling.
6 Configuration - 3 Cooling
KÜHLUNGPOS: XXX
Korroff. to XXK Correction offset which is applied to the t0 actual value received from the pack
controller via CAN bus. This enables pressure losses in the refrigerant line to be
compensated.Ifthisvalueissetto"–",thecasecontrollerregulatesusingthe
temperature sensors at the evaporator input and output (standalone operation).
Dauerl.Überw. XXm Continuous use monitoring
DG-Betrieb AUS This must be set for UA 131 E to guarantee that the D2D defrost runs correctly. The
defrost timer should be set to EXT when activating this operating mode.
Lüfterverzöger XX°C Maximum value at the defrost sensor, at which the fan should be switched on after a
delay (e.g. after the defrost)
8.ExittheConfiguration menu by tapping the ESC button twice and select 3Clock–2Defrosttimer
Inputoftherelevantparametersinthefollowingscreen.
3 Clock - 2 Defrost Timer
ABTAUUHRPOS: XXX
AbtauuhrINT Selection of defrost using external or internal defrost timer
Sicherheitsz.60m Safe defrost time; the defrost is not longer than this time.
Defrost 1 DD-DD hh:mm Entry of defrost times
Defrost 2 DD-DD hh:mm
...
Defrost 14 DD-DD hh:mm
man. AbtauungAUS Manual defrost ON/OFF
9.Exitfromthe2 Defrost Timer menu by tapping the ESC button.
