ECKELMANN Case Controller UA 4 E Series - Page 138

Firmware V3.13
21.04.2021
138/466
12.Selectmenu2 Setpoints - 1 Cooling - Zone 1 / Zone 2 / Zone 1U / Zone 2U.
2 Setpoints - 1 Cooling - Zone 1 - 2 - Um1 - Um2
KÜHLUNG x POS: XXX
...
Überhitzung XK Superheat setpoint of the superheat controller
Min. Überh.XK If the minimum superheat is undercut, the controller closes the associated E-
vale and sets the I-sum (NOT: I-component) to 0 if the parameter Reset I-
Summ is set to ON.
Zweipunktreg. AUS The temperature control no longer operates continuously but as on-off
controller. This is used for enable / disable of the superheat control (TEV
emulation).
MOP-Punkt XX°C Avaluenotequalto"–"mustbesethereiftheMOPfunctionisrequired.Ift0
exceeds this value, the opening degree is reduced as t0 rises.
13.Returntothemainmenuofthestorecomputer/operatorterminalbytappingtheESC button multiple
times.
14.Selectthemenu7 Monitoring - 3 Configuration in the main menu of the store computer / operator
terminalandinput,amongotherthings,thenodenameofthecasecontrollerinplaintext.
7 Monitoring - 3 Configuration
KONFIGURATION Kn.nnn Input of the CAN bus address: Select the case controller with the corresponding
CAN bus address (node No. = 1..99) to be parametrised using the cursor or by
direct input.
Teilnehmername Input node name (e.g. Cheese Counter)
Position XXXXX Input of the position of the node in the store
Priorität X Input of the desired priority
15. Ending basic configuration of the controller
Tap the ESC button multiple times to return to the main menu. This ends the basic configuration of the
controller.
