Menu 2-4-4 Zone 2T Toggle
ALARM 2U POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High Temperature
alarm is generated
-20..30 -14 °C
Low Temp Setp. XX K Temperature setpoint (difference below temperature
control setpoint) at which Low Temperature alarm is
generated
--, 0..6 4 K
Menu 2-5 Frame Heater
FRAME HTR POS: XXXXX
1 Mode frm htr Move to menu 2-5-1
2 Setpoint frm htr Move to menu 2-5-2
3 Mode altern. Move to menu 2-5-3; not shown when setpoint toggle is deactivated (Menu 3-3)
4 Setpoint altern. Move to menu 2-5-4; not shown when setpoint toggle is deactivated (Menu 3-3)
Menu 2-5-1 Frame Mode
Selection is made according to entry. Checkmark shows current setting.
MODE POS: XXXXX Entry Default
Fixed run time
Enthalpy-ctrl rtm
setpoint-ctrlrtm√ √
