ECKELMANN Case Controller UA 4 E Series - Page 246

Firmware V3.13
21.04.2021
246/466
•
•
•
Menu 2-5-2 Frame Setpoints
SETPOINTS POS: XXXXX Entry Default
Mod: xxxxxxxxxxxx Displays set frame mode (Menu 2-5-1) set point-ctrl
runtime
Run Time XXX % Fixed on time, shown only when mode set to
Fixed OT (Menu 2-5-1)
--, 0..100 100 %
emerg.run time XXX % On time in loss of huimidity or room air
temperature (via CAN bus); shown only when
mode set to Enthalpy Control (Menu 2-5-1)
--, 0..100 100 %
enthalp. offs. XXX % Offset for on time when enthalpy control is
activated (via CAN bus); shown only when mode
set to Enthalpy Control (Menu 2-5-1)
-50..50 0 %
Invert Output xxx Inversion of the function of the frame heater
output (terminals 91/92)
↑,↓,
(ON/OFF)
ON
Menu 2-5-3 Toggle Mode
Selection is made according to entry. Checkmark show current setting.
MODUS UM. POS: XXXXX Entry Default
feste ED
Enthalpieregelung
Sollwertabhäng.ED√ √
Menu 2-5-4 Setpoint Toggle
TOG. SETP. POS: XXXXX Entry Default
Mod: xxxxxxxxxxxx Displays set frame mode (Menu 2-5-3) Sollwertabhäng.
ED
Run Time XXX % Fixed on time, shown only when mode set to
Fixed OT (Menu 2-5-3)
--, 0..100 100 %
emerg.run time XXX % On time in loss of huimidity or room air
temperature (via CAN bus); shown only when
mode set to Enthalpy Control (Menu 2-5-3)
--, 0..100 100 %
enthalp. offs. XXX % Offset for on time when enthalpy control is
activated (via CAN bus); shown only when mode
set to Enthalpy Control (Menu 2-5-3)
-50..50 0 %
