Menu 2-6 Fans
Controller type UA 131 E:
with fan control Menus 2-6 / 2-6-1 / 2-6-2 are only show when the case controller is configured to UA 131 with
fan control (further details in the chapter Installation and Startup of UA 4xx E):
FANS POS: XXXXX
1 Zone 1+2 Move to menu 2-6-1
2 Zone 1+2 Altern. Move to menu 2-6-2; shown only when setpoint toggle is activated (Menu 3-3)
Menu 2-6-1 Zone 1+2
FANS POS: XXXXX Entry Default
Fans Start XXX °C Fan start temperature setpoint --, -20..20 –°C
Menu 2-6-2 Zone 1+2 Toggle
FANS A POS: XXXXX Entry Default
Fans Start XXX °C Fan start temperature setpoint --, -20..20 –°C
Controller type UA 131 E LS:
with advanced fan control Menu 2-6 only shown when the case controller is configured to UA 131 LS with
advancedfancontrol(furtherdetailsinthechapterInstallation and Startup of UA 4xx E):
FANS POS: XXXXX
1 Zone 1+2 Move to menu 2-6-1
Menu 2-6-1 Zone 1+2
FANS POS: XXXXX Entry Default
Op.mode: XXXXXXXXXXXX Possible operating modes:
Continuous operation, Forerun, Overrun
CONTINUOUS
FORERUN
OVERRUN
DEL.A.DEFR.
CONTINUOUS
Fans Start Continuous operation mode: not relevant
Forerun mode: not relevant
Overrun mode: Fan on by undershoot of
temperature at
evaporator sensor
Delay after defrost mode: Fan on by
undershoot of temperature
at evaporator sensor
--, -20..20 –°C
Fan hightemp. Continuous operation mode: not relevant
Forerun mode: fan on when temperature at
evaporator
sensor exceeded
Overrun mode: fan off when temperature at
evaporator
sensor exceeded
Delay after defrost mode: not relevant
-30..30 5 °C
