ECKELMANN Case Controller UA 4 E Series - Page 282

Firmware V3.13
21.04.2021
282/466
•
•
•
Menu 2-1-3 Zone 1T Toggle
COOLING 1A POS: XXXXX Entry Default
Setpoint R2.1 XXX °C Supply air temperature setpoint --, -20..20 -2 °C
Hysterese R2.1 X K Supply air temperature hysteresis setpoint; shown
only when on-off control is set (Menu 2-1-1)
1..8 2 K
Setpoint R4.1 XXX °C Return air temperature setpoint --, -15..20 2 °C
Hystersis R4.1 X K Return air temperature hysteresis setpoint; shown
only when on-off control is set (Menu 2-1-1)
1..8 2 K
Menu 2-1-4 Zone 2T Toggle
COOLING 2A POS: XXXXX Entry Default
Setpoint R2.2 XXX °C Supply air temperature setpoint --, -20..20 -2 °C
Hystersis R2.2 X K Supply air temperature hysteresis setpoint; shown
only when on-off control is set (Menu 2-1-2)
1..8 2 K
Setpoint R4.2 XXX °C Return air temperature setpoint --, -15..20 2 °C
Hystersis R4.2 X K Return air temperature hysteresis setpoint; shown
only when on-off control is set (Menu 2-1-2)
1..8 2 K
Menu 2-2 Defrost
DEFROST POS: XXXXX
1 Zone 1 Move to menu 2-2-1
2 Zone 2 Move to menu 2-2-2; shown only when two-zone operation is set (Menu 6-1)
3 Zone 1T Toggle Move to menu 2-2-3; not shown when setpoint toggle is deactivated (Menu 3-3)
4 Zone 2T Toggle Move to menu 2-2-4; shown only when two-zone operation is set (Menu 6-1) and
when
setpoint toggle is not deactivated (Menu 3-3)
