Menu 2-1-2 Zone 2
COOLING 2 POS: XXXXX Entry Default
Setpoint R4.2 XXX °C Refrigerant temperature setpoint --, -45..40 5 °C
Hystersis R4.2 X K Refrigerant temperature hysteresis setpoint; shown
only when on-off control is set (Menu 2-1-2)
1..10 2 K
Superheat XXX K Superheat setpoint Zone 2 0..20 8 K
Min. SH XX K Minimum superheat setpoint, below which cooling relay
switches off in Zone 2. I-sum (not I-part) is set to zero
when the Reset I-Sum parameter is set to ON.
0..10 2 K
Two pos.ctrl XXX Switch between on-off control (ON) and continuous
control (OFF)
↑,↓
(ON/OFF)
OFF
MOP-point XXX °C Starting setpoint for MOP mode --, -50..50 -- °C
Cool. on AOUT XXX% Kühlung eingeschaltet: fester Wert 0..10 V für
Analogausgang AO2; nur sichtbar, wenn von DIP-
Schalter S3 der Kodierschalter 6 auf ON steht, siehe
Kapitel Funktionsweise der Analogausgänge 0..10 V.
0..100 80 %
Cool. off AOUT XXX% Kühlung ausgeschaltet: fester Wert 0..10 V für
Analogausgang AO2; nur sichtbar, wenn von DIP-
Schalter S3 der Kodierschalter 6 auf ON steht, siehe
Kapitel Funktionsweise der Analogausgänge 0..10 V.
0..100 50 %
Menu 2-1-3 Zone 1T Toggle
COOLING 1A POS: XXXXX Entry Default
Setpoint R4.1 XXX °C Refrigerant temperature setpoint --, -45..40 5 °C
Hystersis R4.1 X K Refrigerant temperature hysteresis setpoint; shown
only when on-off control is set (Menu 2-1-1)
1..10 2 K
Menu 2-1-4 Zone 2T Toggle
COOLING 2A POS: XXXXX Entry Default
Setpoint R4.2 XXX °C Refrigerant temperature setpoint --, -45..40 5 °C
Hystersis R4.2 X K Refrigerant temperature hysteresis setpoint; shown
only when on-off control is set (Menu 2-1-2)
1..10 2 K
Menu 2-2 Defrost
DEFROST POS: XXXXX
1 Zone 1 Move to menu 2-2-1
2 Zone 2 Move to menu 2-2-2; shown only when two-zone operation is set (Menu 6-1)
3 Zone 1T Toggle Move to menu 2-2-3; not shown when setpoint toggle is deactivated (Menu 3-3)
4 Zone 2T Toggle Move to menu 2-2-4; shown only when two-zone operation is set (Menu 6-1) and when
setpoint toggle is not deactivated (Menu 3-3)
