ECKELMANN Case Controller UA 4 E Series - Page 398

Firmware V3.13
21.04.2021
398/466
•
•
•
•
•
•
Menu 2-3 Not used with this controller type.
Menu 2-4 Alarm
ALARM POS: XXXXX
1 Zone 1 Move to menu 2-4-1
2 Zone 2 Move to menu 2-4-2; shown only when two-zone operation is set (Menu 6-1)
3 Zone 1T Toggle Move to menu 2-4-3; not shown when setpoint toggle is deactivated (Menu 3-3)
4 Zone 2T Toggle Move to menu 2-4-4; shown only when two-zone operation is set (Menu 6-1) and when
setpoint toggle is not deactivated (Menu 3-3)
Menu 2-4-1 Zone 1
ALARM 1 POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High
Temperature alarm is generated
-35..45 45 °C
Low Temp Setp. XX K Temperature setpoint (difference below
temperature control setpoint) at which Low
Temperature alarm is generated
--, 0..10 -- K
Menu 2-4-2 Zone 2
ALARM 2 POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High
Temperature alarm is generated
-35..45 45 °C
Low Temp Setp. XX K Sollwert Temperatur (Differenz unter dem Sollwert
der Temperaturregelung), bei dem der Alarm
Untertemperatur ausgelöst wird
--, 0..10 -- K
Menu 2-4-3 Zone 1T Toggle
ALARM 1A POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High
Temperature alarm is generated
-35..45 45 °C
Low Temp Setp. XX K Temperature setpoint (difference below
temperature control setpoint) at which Low
Temperature alarm is generated
--, 0..10 -- K
Menu 2-4-4 Zone 2T Toggle
ALARM 2A POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High
Temperature alarm is generated
-35..45 45 °C
Low Temp Setp. XX K Temperature setpoint (difference below
temperature control setpoint) at which Low
Temperature alarm is generated
--, 0..10 -- K
