Parts List and Schematics
Appendix A. Advanced Protocol Parameter List
Note: Parameters are for all Serinus series analysers and may not be applicable to an individual
instrument.
Table 25 – Advanced Protocol Parameter List
#
Description
Notes
1
Cal/Zero Valve
0 = Zero, 1 = Cal
2
Internal Span Valve
0 = OFF, 1 = ON
3
+Analog Supply
Positive analog supply voltage
4
Gas 5 Avg.
Average of the readings (for Gas5) of the last n minutes where
n is the averaging period E.g. Nx
5
Pregain
S30H linearization coefficient gain
6
Sample/Cal Valve
0 = Sample, 1 = Cal/Zero
7
NOx Measure Valve
0 = NO, 1 = NOx
8
NOx Bypass Valve
0 = NO, 1 = NOx
9
NOx Backgnd Valve
0 = OFF, 1 = ON
10
Valve Sequencing
0 = OFF, 1 = ON
11
LCD Contrast Pot
0 = Lightest, 255 = Darkest
12
SO2 Ref Zero Pot
S50 Reference zero pot
13
CO Input Pot
S30 Input pot
14
CO Reference Test Pot
Not Used
15
CO Test Measure Pot
Not Used
16
High Volt Adjust Pot
PMT High Voltage Adjust Pot for S50 & S40
17
SO2 Lamp Adjust Pot
S50 Lamp adjustment Pot
18
O3 Lamp Adjust Pot
S10 Lamp adjustment Pot
19
O3 Meas. Zero Pot (C)
S10 Signal zero measure (coarse)
20
O3 Meas. Zero Pot (F)
S10 Signal zero measure (fine)
21
PMT Fan Pot
Optical Bench fan speed control pot
22
Rear Fan Pot
Chassis Fan speed control pot
23
Pump Fine Pot
Internal Pump speed fine pot
24
Pump Coarse Pot
Internal Pump speed coarse pot
25
Analog input 0
SO2 Reference signal
26
Analog input 1
CO Reference signal
27
Analog input 2
O3 Reference signal
28
Analog input 3
SO2 & O3 Lamp current
29
Analog input 4
Flow block pressure
