System integration Proline Promass E 500 PROFIBUS PA
104 Endress+Hauser
Assignment of medium type: function block DO 5
112 Methanol in water
113 Ammonium nitrate in water
114 Iron(III) chloride in water
115 HFCS42
116 HFCS55
117 HFCS90
118 Original wort
119 % mass / % volume
121 Coef Set No. 1
122 Coef Set No. 2
123 Coef Set No. 3
124 Hydrochloric acid
125 Sulfuric acid
Data structure
Output data of Discrete Output
Byte 1 Byte 2
Discrete Status
EMPTY_MODULE module
This module is used to assign empty spaces arising from modules not being used in the
slots .
The measuring device works as a modular PROFIBUS slave. In contrast to a compact slave,
a modular PROFIBUS slave has a variable design and consists of several individual
modules. The GSD file contains a description of the individual modules along with their
individual properties.
The modules are permanently assigned to the slots. When configuring the modules, it is
absolutely essential to observe the sequence/arrangement of the modules. Any gaps
between the configured modules must be filled with the EMPTY_MODULE.
