Proline Promass E 500 PROFIBUS PA System integration
Endress+Hauser 93
9.2.1 Manufacturer-specific GSD
This GSD guarantees the unrestricted functionality of the measuring device. Device-specific
process parameters and functions are therefore available.
Manufacturer-specific GSD ID number File name
PROFIBUS PA 0x156D EH3x156D.gsd
Use manufacturer-specific GSD
Assignment is performed in the Ident number selector parameter via the Manufacturer
option.
Sources of supply for the manufacturer-specific GSD:
• Export directly from the device via the integrated web server:
Data management→ Documents → Export GSD file
• Download via the Endress+Hauser website:
www.endress.com → Download-Area
9.2.2 Profile GSD
Differs in terms of the number of Analog Input blocks (AI) and the measured values. If a
system is configured with a Profile GSD, it is possible to exchange devices made by
different manufacturers. However, it is essential to ensure that the order of the cyclic
process values is correct.
ID number Supported blocks Supported channels
0x9740 • 1 Analog Input
• 1 Totalizer
• Channel Analog Input: volume flow
• Channel totalizer: volume flow
0x9741 • 2 Analog Input
• 1 Totalizer
• Channel Analog Input 1: volume flow
• Channel Analog Input 2: mass flow
• Channel totalizer: volume flow
0x9742 • 3 Analog Input
• 1 Totalizer
• Channel Analog Input 1: volume flow
• Channel Analog Input 2: mass flow
• Channel Analog Input 3: corrected volume
flow
• Channel totalizer: volume flow
Use profile GSD
Assignment is performed in the Ident number selector parameter:
• ID number 0x9740: 1 AI, 1 Totalizer (0x9740) option
• ID number 0x9741: 2 AI, 1 Totalizer (0x9741) option
• ID number 0x9742: Profile option
