Proline Promass E 500 PROFIBUS PA System integration
Endress+Hauser 99
Input variable
Alternative GSV flow
3)
NSV flow
3)
Alternative NSV flow
3)
S&W volume flow
3)
Water cut percentage
3)
Oil density
3)
Water density
3)
Oil mass flow
3)
Water mass flow
3)
Oil volume flow
3)
Water volume flow
3)
Oil corrected volume flow
3)
Water corrected volume flow
3)
1) Only available with the Concentration application package
2) Only available with the Heartbeat Verification application package
3) Only available with the Petroleum application package
Factory setting
Function block Factory setting
AI 1 Mass flow
AI 2 Volume flow
AI 3 Corrected volume flow
AI 4 Density
AI 5 Mass flow
AI 6 Temperature
AI 7 Mass flow
AI 8 Mass flow
Data structure
Input data of Analog Input
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5
Measured value: floating point number (IEEE 754) Status
TOTAL module
Transmit a totalizer value from the measuring device to the PROFIBUS master (Class 1).
A selected totalizer value, along with the status, is cyclically transmitted to a PROFIBUS
Master (Class 1) via the TOTAL module. The totalizer value is depicted in the first four
bytes in the form of a floating point number as per the IEEE 754 standard. The fifth byte
contains standardized status information pertaining to the totalizer value.
Three Totalizer blocks are available (slot 9 to 11).
