Commissioning Proline Promass E 500 PROFIBUS PA
114 Endress+Hauser
Parameter overview with brief description
Parameter Prerequisite Description Selection / User entry
Channel – Select the process variable. • Mass flow
• Volume flow
• Corrected volume flow
*
• Density
• Reference density
*
• Target mass flow
*
• Carrier mass flow
*
• Concentration
*
• Target volume flow
*
• Carrier volume flow
*
• Target corrected volume
flow
*
• Carrier corrected volume
flow
*
• Temperature
• Electronic temperature
• Oscillation frequency 0
• Frequency fluctuation 0
*
• Oscillation damping 0
*
• Oscillation damping
fluctuation 0
*
• Oscillation damping
fluctuation 1
*
• Signal asymmetry
*
• Exciter current 0
*
• Current input 1
*
• Reference density
alternative
*
• GSV flow
*
• GSV flow alternative
*
• NSV flow
*
• NSV flow alternative
*
• S&W volume flow
*
• Oil density
*
• Water density
*
• Water cut
*
• Oil mass flow
*
• Water mass flow
*
• Oil volume flow
*
• Water volume flow
*
• Oil corrected volume
flow
*
• Water corrected volume
flow
*
PV filter time – Specify the time to suppress signal
peaks. During the specified time the
Analog Input does not respond to an
erratic increase in the process variable.
Positive floating-point
number
Fail safe type – Select the failure mode. • Fail-safe value
• Fallback value
• Off
Fail-safe value In Fail safe type parameter, the Fail-
safe value option is selected.
Specify the values to be output when an
error occurs.
Signed floating-point
number
* Visibility depends on order options or device settings
10.6.6 Displaying the I/O configuration
The I/O configuration submenu guides the user systematically through all the parameters
in which the configuration of the I/O modules is displayed.
