Installation Proline Promass E 500 PROFIBUS PA
28 Endress+Hauser
Verification and adjustment cannot be carried out if the following process conditions are
present:
• Gas pockets
Ensure that the system has been sufficiently flushed with the medium. Repeat flushing
can help to eliminate gas pockets
• Thermal circulation
In the event of temperature differences (e.g. between the measuring tube inlet and
outlet section), induced flow can occur even if the valves are closed due to thermal
circulation in the device
• Leaks at the valves
If the valves are not leak-tight, flow is not sufficiently prevented when determining the
zero point
If these conditions cannot be avoided, it is advisable to keep the factory setting for the zero
point.
Weather protection cover
213 (8.4)
39 (1.5)
243 (9.6)
203 (8.0)
A0029552
10 Weather protection cover for Proline 500 – digital; engineering unit mm (in)
146 (5.75)
48 (1.9)
12 (0.47)
280 (11.0) 255 (10.0)
134 (5.3)
30 (1.18)
A0029553
11 Weather protection cover for Proline 500; engineering unit mm (in)
Cover locking: Proline 500
NOTICE
Order code "Transmitter housing", option L "Cast, stainless": The covers of the
transmitter housing are provided with a borehole to lock the cover.
The cover can be locked using screws and a chain or cable provided by the customer on
site.
‣
The use of stainless steel chains or cables is recommended.
‣
If a protective coating is applied, it is recommended to use a heat shrink tube to protect
the housing paint.
