9.5 Cyclic data transmission
Cyclic data transmission when using the device master file (GSD).
9.5.1 Block model
The block model shows which input and output data the measuring device makes available
for cyclic data exchange. Cyclic data exchange takes place with a PROFIBUS master (Class
1), e.g. a control system.
Measuring instrument Control system
Flow
Block
Analog Input block 1 to 8 →  98 Output value AI →
PROFIBUS PA
Totalizer block 1 to 3 →  99
Output value TOTAL →
Controller SETTOT ←
Configuration MODETOT ←
Analog Output block 1 to
3
→  101 Input values AO ←
Discrete Input block 1 to 2 →  102 Output values DI →
Discrete Output block 1 to
4
→  103 Input values DO ←
Defined order of modules
The measuring device works as a modular PROFIBUS slave. In contrast to a compact slave,
a modular slave has a variable design and consists of several individual modules. The
device master file (GSD) contains a description of the individual modules (input and output
data) along with their individual properties.
The modules are permanently assigned to the slots, i.e. when configuring the modules, the
order and the arrangement of the modules must be respected.
Slot Module Function block
1 to 8 AI Analog Input block 1 to 8
9
TOTAL or
SETTOT_TOTAL or
SETOT_MODETOT_TOTAL
Totalizer block 1
10 Totalizer block 2
11 Totalizer block 3
12 to 14 AO Analog Output block 1 to 3
15 to 16 DI Discrete Input block 1 to 2
17 to 21 DO Discrete Output block 1 to 5
22 to 23 AO Analog Output block 4 to 5
To optimize the data throughput rate of the PROFIBUS network, it is advisable to only
configure modules that are processed in the PROFIBUS master system. If this results in
gaps between the configured modules, these gaps must be assigned to the
EMPTY_MODULE.
9.5.2 Description of the modules
The data structure is described from the perspective of the PROFIBUS master:
• Input data: Are sent from the measuring device to the PROFIBUS master.
• Output data: Are sent from the PROFIBUS master to the measuring device.
