10.6.14 Configuring partially filled pipe detection
The Partial filled pipe detection wizard guides you systematically through all parameters
that have to be set for configuring the monitoring of the pipe filling.
Navigation
"Setup" menu → Partially filled pipe detection
‣
Partially filled pipe detection
Assign process variable
→  137
Low value partial filled pipe detection
→  137
High value partial filled pipe detection
→  137
Response time part. filled pipe detect.
→  137
Parameter overview with brief description
Parameter Prerequisite Description Selection / User
entry
Factory setting
Assign process variable – Select process variable for
partially filled pipe detection.
• Off
• Density
• Reference density
Density
Low value partial filled pipe
detection
A process variable is selected
in the Assign process variable
parameter (→  137).
Enter lower limit value for
deactivating partialy filled pipe
detection.
Signed floating-point
number
Depends on country:
• 200 kg/m
3
• 12.5 lb/ft
3
High value partial filled pipe
detection
A process variable is selected
in the Assign process variable
parameter (→  137).
Enter upper limit value for
deactivating partialy filled pipe
detection.
Signed floating-point
number
Depends on country:
• 6 000 kg/m
3
• 374.6 lb/ft
3
Response time part. filled pipe
detect.
A process variable is selected
in the Assign process variable
parameter (→  137).
Use this function to enter the
minimum time (hold time) the
signal must be present before
diagnostic message S962 "Pipe
only partly filled" is triggered in
the event of a partially filled or
empty measuring pipe.
0 to 100 s –
