Proline Promass E 500 PROFIBUS PA Diagnostics and troubleshooting
Endress+Hauser 197
Diagnostic behavior
(configurable)
Measured value status (fixed assignment)
Device diagnosis
(fixed assignment)
Quality
Quality
Substatus
Coding
(hex)
Category
(NE107)
Logbook entry only
GOOD ok 0x80 to 0x8E – –
Off
12.7 Overview of diagnostic information
• The amount of diagnostic information and the number of measured variables
affected increase if the measuring device has one or more application packages.
• All of the measured variables affected in the entire Promass instrument family are
always listed under "Measured variables affected". The measured variables available
for the device in question depend on the device version. When assigning the
measured variables to the device functions, for example to the individual outputs, all
of the measured variables available for the device version in question are available
for selection.
In the case of some items of diagnostic information, the diagnostic behavior can be
changed. Adapting the diagnostic information →  194
12.7.1 Diagnostic of sensor
Diagnostic information Remedy instructions
No. Short text
022 Temperature sensor defective 1. Check or replace sensor electronic module (ISEM)
2. If available: Check connection cable between sensor and transmitter
3. Replace sensor
Measured variable status
Quality Bad
Quality substatus Maintenance alarm
Coding (hex) 0x24 to 0x27
Status signal F
Diagnostic behavior Alarm
Influenced measured variables
• Oscillation amplitude 1
• Oscillation amplitude 2
• Signal asymmetry
• Carrier mass flow
• Carrier pipe temperature
• Target corrected volume flow
• Carrier corrected volume flow
• Concentration
• Oscillation damping 1
• Oscillation damping 2
• Density
• Oil density
• Water density
• Dynamic viscosity
• Sensor electronic temperature (ISEM)
• Empty pipe detection option
• GSV flow
• GSV flow alternative
• Kinematic viscosity
• Low flow cut off option
• Mass flow
• Oil mass flow
• Water mass flow
• HBSI
• NSV flow
• NSV flow alternative
• External pressure
• Exciter current 1
• Exciter current 2
• Oscillation frequency 1
• Oscillation frequency 2
• S&W volume flow
• Reference density
• Reference density alternative
• Corrected volume flow
• Oil corrected volume flow
• Water corrected volume flow
• Oscillation damping fluctuation 1
• Oscillation damping fluctuation 2
• Frequency fluctuation 1
• Frequency fluctuation 2
• Target mass flow
• Carrier volume flow
• Target volume flow
• Temp. compensated dynamic viscosity
• Temp. compensated kinematic viscosity
• Temperature
• Status
• Volume flow
• Oil volume flow
• Water volume flow
• Water cut
