Diagnostics and troubleshooting Proline Promass E 500 PROFIBUS PA
196 Endress+Hauser
Diagnostic information pertaining to the electronics: diagnostic number 200 to 399
Diagnostic number 200 to 301, 303 to 399
Diagnostic behavior
(configurable)
Measured value status (fixed assignment)
Device diagnostics
(fixed assignment)
Quality
Quality
Substatus
Coding
(hex)
Category
(NE107)
Alarm
BAD
Maintenance
alarm
0x24 to 0x27
F
(Failure)
Maintenance
alarm
Warning
Logbook entry only
GOOD ok 0x80 to 0x8E – –
Off
Diagnostic information 302
Diagnostic behavior
(configurable)
Measured value status (fixed assignment)
Device diagnostics
(fixed assignment)
Quality
Quality
Substatus
Coding
(hex)
Category
(NE107)
Alarm BAD
Function check,
local override
0x24 to 0x27 C Function check
Warning GOOD Function check 0xBC to 0xBF – –
Data logging continues when Heartbeat Verification is started. The signal outputs and
totalizers are not affected.
• Signal status: Function check
• Choice of diagnostic behavior: alarm or warning (factory setting)
When the Heartbeat Verification is started, data logging is interrupted, the last valid
measured value is output and the totalizer counter is stopped.
Diagnostic information pertaining to the configuration: diagnostic number 400 to 599
Diagnostic behavior
(configurable)
Measured value status (fixed assignment)
Device diagnosis
(fixed assignment)
Quality
Quality
Substatus
Coding
(hex)
Category
(NE107)
Alarm BAD
Process
related
0x28 to 0x2B
F
(Failure)
Invalid process
condition
Warning
UNCERTA
IN
Process
related
0x78 to 0x7B
S
(Out of
specification)
Invalid process
condition
Logbook entry only
GOOD ok 0x80 to 0x8E – –
Off
Diagnostic information pertaining to the process: diagnostic number 800 to 999
Diagnostic behavior
(configurable)
Measured value status (fixed assignment)
Device diagnosis
(fixed assignment)
Quality
Quality
Substatus
Coding
(hex)
Category
(NE107)
Alarm BAD
Process
related
0x28 to 0x2B
F
(Failure)
Invalid process
condition
Warning
UNCERTA
IN
Process
related
0x78 to 0x7B
S
(Out of
specification)
Invalid process
condition
