Proline Promass E 500 PROFIBUS PA Commissioning
Endress+Hauser 129
Parameter Prerequisite Description Selection / User
interface / User
entry
Factory setting
Assign flow direction check • The Switch option is
selected in the Operating
mode parameter.
• The Flow direction check
option is selected in the
Switch output function
parameter.
Select process variable for flow
direction monitoring.
–
Assign status • The Switch option is
selected in Operating mode
parameter.
• The Status option is
selected in Switch output
function parameter.
Select device status for switch
output.
• Partially filled pipe
detection
• Low flow cut off
• Digital output 4
*
–
Switch-on value • The Switch option is
selected in the Operating
mode parameter.
• The Limit option is selected
in the Switch output
function parameter.
Enter measured value for the
switch-on point.
Signed floating-point
number
Depends on country:
• 0 kg/h
• 0 lb/min
Switch-off value • The Switch option is
selected in the Operating
mode parameter.
• The Limit option is selected
in the Switch output
function parameter.
Enter measured value for the
switch-off point.
Signed floating-point
number
Depends on country:
• 0 kg/h
• 0 lb/min
Switch-on delay • The Switch option is
selected in the Operating
mode parameter.
• The Limit option is selected
in the Switch output
function parameter.
Define delay for the switch-on
of status output.
0.0 to 100.0 s –
Switch-off delay • The Switch option is
selected in the Operating
mode parameter.
• The Limit option is selected
in the Switch output
function parameter.
Define delay for the switch-off
of status output.
0.0 to 100.0 s –
Failure mode – Define output behavior in
alarm condition.
• Actual status
• Open
• Closed
–
Invert output signal – Invert the output signal. • No
• Yes
–
* Visibility depends on order options or device settings
10.6.11 Configuring the relay output
The Relay output wizard guides the user systematically through all the parameters that
have to be set for configuring the relay output.
Navigation
"Setup" menu → Relay output 1 to n
‣
Relay output 1 to n
Terminal number
→  130
