10.6.10 Configuring the pulse/frequency/switch output
The Pulse/frequency/switch output wizard guides you systematically through all the
parameters that can be set for configuring the selected output type.
Navigation
"Setup" menu → Advanced setup → Pulse/frequency/switch output
‣
Pulse/frequency/switch output
1 to n
Operating mode
→  121
Parameter overview with brief description
Parameter Description Selection
Operating mode Define the output as a pulse, frequency or switch output. • Pulse
• Frequency
• Switch
Configuring the pulse output
Navigation
"Setup" menu → Pulse/frequency/switch output
‣
Pulse/frequency/switch output
1 to n
Operating mode
→  122
Terminal number
→  122
Signal mode
→  122
Assign pulse output
→  122
Pulse scaling
→  122
Pulse width
→  122
Failure mode
→  123
Invert output signal
→  123
