Technical data Proline Promass E 500 PROFIBUS PA
272 Endress+Hauser
Supply voltage
Order code
"Power supply"
Terminal voltage Frequency range
Option D DC 24 V ±20% –
Option E AC 100 to 240 V –15…+10% 50/60 Hz
Option I
DC 24 V ±20% –
AC 100 to 240 V –15…+10% 50/60 Hz
Power consumption Transmitter
Max. 10 W (active power)
switch-on current Max. 36 A (<5 ms) as per NAMUR Recommendation NE 21
Current consumption Transmitter
• Max. 400 mA (24 V)
• Max. 200 mA (110 V, 50/60 Hz; 230 V, 50/60 Hz)
Power supply failure • Totalizers stop at the last value measured.
• Depending on the device version, the configuration is retained in the device memory or
in the pluggable data memory (HistoROM DAT).
• Error messages (incl. total operated hours) are stored.
Overcurrent protection
element
The device must be operated with a dedicated circuit breaker, as it does not have an
ON/OFF switch of its own.
• The circuit breaker must be easy to reach and labeled accordingly.
• Permitted nominal current of the circuit breaker: 2 A up to maximum 10 A.
Electrical connection • →  43
• →  50
Potential equalization →  56
Terminals Spring-loaded terminals: Suitable for strands and strands with ferrules.
Conductor cross-section 0.2 to 2.5 mm
2
(24 to 12 AWG).
Cable entries • Cable gland: M20 × 1.5 with cable ⌀ 6 to 12 mm (0.24 to 0.47 in)
• Thread for cable entry:
• NPT ½"
• G ½"
• M20
• Device plug for digital communication: M12
• Device plug for connecting cable: M12
A device plug is always used for the device version with the order code for "Sensor
connection housing", option C "Ultra-compact, hygienic, stainless".
Cable specification →  35
