Technical data Proline Promass E 500 PROFIBUS PA
282 Endress+Hauser
Cable entries and adapters Material
Cable gland M20 × 1.5 Plastic
• Adapter for cable entry with female thread G ½"
• Adapter for cable entry with female thread NPT ½"
Only available for certain device versions:
• Order code for "Transmitter housing":
• Option A "Aluminum, coated"
• Option D "Polycarbonate"
• Order code for "Sensor connection housing":
• Proline 500 – digital:
Option A "Aluminum coated"
Option B "Stainless"
• Proline 500:
Option B "Stainless"
Nickel-plated brass
Adapter for device plug
• Device plug for digital communication:
Only available for certain device versions .
• Device plug for connecting cable:
A device plug is always used for the device version, order
code for "Sensor connection housing", option C (ultra-
compact, hygienic, stainless).
Stainless steel, 1.4404 (316L)
Device plug
Electrical connection Material
Plug M12x1 • Socket: Stainless steel, 1.4404 (316L)
• Contact housing: Polyamide
• Contacts: Gold-plated brass
Connecting cables
UV rays can impair the cable outer sheath. Protect the cable from exposure to sun as
much as possible.
Connecting cable for sensor - Proline 500 – digital transmitter
PVC cable with copper shield
Connecting cable for sensor - Proline 500 transmitter
PVC cable with copper shield
Sensor housing
• Acid and alkali-resistant outer surface
• Stainless steel 1.4301 (304)
Measuring tubes
Stainless steel, 1.4539 (904L); manifold: stainless steel, 1.4404 (316L)
Process connections
• Flanges according to EN 1092-1 (DIN2501) / according to ASME B 16.5 / as per JIS
B2220:
Stainless steel, 1.4404 (F316/F316L)
• All other process connections:
Stainless steel, 1.4404 (316/316L)
Available process connections→ 283
