Electrical connection Proline Promass E 500 PROFIBUS PA
36 Endress+Hauser
Ethernet-APL
Shielded twisted-pair cable. Cable type A is recommended.
See https://www.profibus.com Ethernet-APL White Paper "
Current output 0 /4 to 20 mA (excluding HART)
Standard installation cable is sufficient.
Pulse /frequency /switch output
Standard installation cable is sufficient.
Relay output
Standard installation cable is sufficient.
Current input 4 to 20 mA
Standard installation cable is sufficient.
Status input
Standard installation cable is sufficient.
Cable diameter
• Cable glands supplied:
M20 × 1.5 with cable ⌀ 6 to 12 mm (0.24 to 0.47 in)
• Spring-loaded terminals: Suitable for strands and strands with ferrules.
Conductor cross-section 0.2 to 2.5 mm
2
(24 to 12 AWG).
Choice of connecting cable between the transmitter and sensor
Depends on the type of transmitter and the installation zones
