Endress+Hauser Proline Promass E 500 - Page 46

Electrical connection Proline Promass E 500 PROFIBUS PA
46 Endress+Hauser
Connecting the sensor connection housing via the connector
For the device version with the order code for "Sensor connection housing":
Option C "Ultra-compact hygienic, stainless"
1.
2.
A0029615
1. Connect the protective ground.
2. Connect the connector.
