Epson Artisan 810/835/837/710/725/730/Epson Stylus Photo PX810FW/TX810FW/PX820FWD/TX820FWD/PX830FWD/PX710W/TX710W/PX720WD/TX720WD/PX730WD/TX730WD
Revision G
ADJUSTMENT Adjustment Items and Overview 208
Confidential
Adjustment Items
Case open sensor check
To check if the Cover open sensor operates normally. See "5.2.8 Case Open Sensor Check" (p.220) for information on
how to check.
• Adjustment Program
• Thickness Gauge
0.9 mm, 3.0 mm
Leak check
To check the joint section for leakage when disconnecting the joint
between the printhead and the ink tube.
See the video manual; separately distributed, for the details.
• Leak Check jig
• Air release jig
Table 5-2. Maintenance Items
Adjustment Item Purpose Method Outline Tool
Maintenance Items
Head cleaning
Run this cleaning when dots missing is observed on an adjustment
pattern printed by the adjustment program.
Perform a head cleaning using the adjustment program, and print a
nozzle check pattern to see if all the nozzles fire ink properly.
• Adjustment Program
I/S decompress
To minimize the amount of ink spilling when removing the
printhead, discharge ink in the ink tube via the Ink System (Cap)
out of the printer.
After removing the Waste Ink Tray Assy, select “I/S Decompress”
from the menu of the adjustment program, and operate following
the instruction of the program. See "5.4.1 I/S Decompress" (p.238).
• Adjustment Program
Ink charge
This must be carried out after replacing the Printhead in order to fill
ink inside the all nozzles of the new ASP Printhead.
After installing the Waste Ink Tray Assy, perform an ink charge
using the adjustment program, and print a nozzle check pattern to
see if all the nozzles fire ink properly. The auto cleaning is also
settable.
• Adjustment Program
Consumables maintenance
counter
The printer causes a maintenance error when the waste ink pad
counter reaches its maximum. Use this to reset the counter after
replacing the Waste Ink Pad. If you find the counter is close to the
maximum during servicing, carry out the pad replacement and the
counter reset to avoid the printer returned from the user due to the
maintenance error.
Replace the waste ink pads (Waste Ink Tray Assy/Lower Paper
Guide Waste Ink Pad Assy), and reset the counter to the default.
• Adjustment Program
CD-R print counter clear
Initializes the CD-R print counter when replacing the CDR tray to
reset the correction value for the CDR tray’s deterioration applied
according to the CD-R print counter.
Initialize the CD-R print counter using the adjustment program.
• Adjustment Program
AID SHK error reset
(Artisan 810/710/PX810FW/
TX810FW/PX710W/
TX710W only)
Resets the AID SHK error counter to confirm the cause is on either
of AID board, the printhead or any other part when a fatal error
related to AID (AID SHK error) occurs. This cancels the fatal error
to specify the error part.
Initialize the AID SHK error counter and troubleshoot the error
part. See "5.4.2 AID SHK Error Reset" (p.239).
• Adjustment Program
Table 5-1. Adjustment Items
Adjustment Item Purpose Method Outline Tool
