Epson Artisan 730 - Control Panel Functions in each Mode; Control Panel Functions

Epson Artisan 810/835/837/710/725/730/Epson Stylus Photo PX810FW/TX810FW/PX820FWD/TX820FWD/PX830FWD/PX710W/TX710W/PX720WD/TX720WD/PX730WD/TX730WD Revision G
PRODUCT DESCRIPTION Control Panel 29
Confidential
1.6.2 Control Panel Functions in Each Mode
1.6.2.1 Control Panel Functions
The table below shows the print setting menu items for each mode and their defaults,
and when the settings are saved or returned to their defaults. Explanations on detailed
control panel functions of the Epson Artisan 810/Epson Stylus Photo PX810FW/
TX810FW/Epson Artisan 710/Epson Stylus Photo PX710W/TX710W are omitted
here, because the LCD displays the detailed instruction.
Table 1-22. Button Functions
(Epson Artisan 810/Epson Stylus Photo PX810FW/TX810FW)
Button Function
Power Turns the power ON/OFF.
Touch Panel Displays available buttons in each mode.
Unlock button
Release the lock of tilt adjustment of the Control Panel while
pressing.
CD Tray Ejects/retracts the CDR Tray.
Table 1-23. Button Functions
(Epson Artisan 710/Epson Stylus Photo PX710W/TX710W)
Button Function
Power
Turns the power ON/OFF.
Display/Crop
• Goes to the zoom setting screen for the selected image.
• Changes the image preview layout on the LCD.
-, + Sets pages to print
Unlock Release the lock of the Control Panel.
Start Starts printing.
Stop/Clear Settings
• Stops operation and displays the menu screen.
• Stops printing and ejects paper.
• Returns the print settings in the current mode to their defaults
and displays the Top screen. (Returns to the previous screen
during printing maintaining the current settings)
Back Cancels the previous operation.
Cross Key/OK
• Selects a menu item or a setting value.
• Accepts the changed settings
Menu Goes to the menu screen for each mode.
Auto Correct Changes the Auto Correct ON/OFF.
CD Tray Ejects/retracts the CDR Tray.
Home
Changes modes in the following order.
Copy/Print Photos/Scan/Setup
Table 1-24. LED
LED Function
Power (Green)
• Flashes while powering ON/OFF.
• Flashes during some sequence is in progress.
• Flashes when a fatal/maintenance error occurs.
• Lights when the status is other than above.
(Stand by mode/during setting on the Panel, etc.)
Blue status light Flashes or lights according to the printer status.
Table 1-25. Timing of Saving or Initializing Control Panel Settings
Mode Print Setting Default Value
Copy Normal Copy Copy Type Color
Density ±0
Layout With Border
2-Sided Printing Off
Reduce/Enlarge Actual
Paper Size
• EAI: Letter
• Euro/Asia: A4
Paper Type Plain Paper
Document Type Text & Image
Quality Standard Quality
Expansion Standard
Dry Time Standard
Binding Direction Vertical-Long
