Epson Artisan 810/835/837/710/725/730/Epson Stylus Photo PX810FW/TX810FW/PX820FWD/TX820FWD/PX830FWD/PX710W/TX710W/PX720WD/TX720WD/PX730WD/TX730WD

Revision G

DISASSEMBLY/ASSEMBLY Disassembly Procedures 126

Confidential

4.2.4.2 Main Board / Grounding Plate M/B

 Parts/Components need to be removed in advance:

ADF Unit/Scanner Unit/Upper Left Housing/Paper Guide Top Assy/Upper

Housing/Hinge/Rear Right FAX Housing/Right Housing

 Removal procedure

1. Disconnect all the cables and FFCs from the connectors on the Main Board.

Note * : Artisan 837/730/PX830FWD/PX730WD/TX730WD only

C H E C K

P O I N T

The disassembly/reassembly procedures for Artisan 710/725/730/

PX710W/TX710W/PX720WD/TX720WD/PX730WD/TX730WD

differ from those for Artisan 810/835/837/PX810FW/TX810FW/

PX820FWD/TX820FWD/PX830FWD. See

"4.3.2.2 Main Board/

Grounding Plate M/B" (p.190) for the procedures.

C A U T I O N

When printing the CDR, the CDR Tray feed amount is adjusted

with compensation considering the deterioration of the CDR Tray,

and the correction level is determined by the number of printed

CDRs. If the data on the EEPROM can not be copied when

replacing the Main Board, banding may occur while printing CDR

due to improper corrections caused because the data of the number

of printed CDRs can not be transferred.

When this happens, replace the CDR Tray Assy with a new one

together with the Main Board. (See

"4.2.5.9 CDR Tray Assy"

(p.153).)

Table 4-4. Connectors on the Main Board

No.

Cable/FFC

Connector

Color

Number of pins

Artisan 810/835/

837/PX810FW/

TX810FW/

PX820FWD/

TX820FWD/

PX830FWD

Artisan 710/725/

730/PX710W/

TX710W/

PX720WD/

TX720WD/

PX730WD/

TX730WD

CN1 Head FFC -- 14

CN2 Head FFC -- 14

CN3 Head FFC -- 14

CN4 Head FFC -- 14

CN5 CSIC FFC -- 13

CN6 CR Encoder FFC -- 8

CN7 SUB FFC -- 9

CN8 PF Encoder FFC -- 4

CN9 PE Sensor Cable White 3

CN10 Scanner Cover Open Sensor FFC -- 4

CN12 Photo Tray Sensor Cable Yellow 2

CN13 Duplex Unit Sensor Cable White 2

CN19 Plunger Cable

Black 2

CN21 CR Motor Cable Black 2

CN22 PF Motor Cable White 2

CN24

Decompression Pump Motor

Cable

Red 2

CN25 ADF Motor Cable Black 4 ---

CN31 STG FFC -- 8

CN33 Panel FFC -- 28 19

CN36 I/F B FFC (FAX) -- 18 ---

CN41 Scanner Carriage FFC -- 15

CN49 Scanner CR Encoder FFC -- 6

CN51 ADF Sensor Cable White 5 ---

CN501 Power Supply Unit Cable White 6
