Epson Artisan 810/835/837/710/725/730/Epson Stylus Photo PX810FW/TX810FW/PX820FWD/TX820FWD/PX830FWD/PX710W/TX710W/PX720WD/TX720WD/PX730WD/TX730WD Revision G
ADJUSTMENT Adjustment Using Adjustment Program 218
Confidential
 Setting procedure
1. Start the adjustment program.
2. Select “Initial setting” from the menu. The Initial setting screen appears.
3. Check the “MAC Address” checkbox and enter the last six digits of the MAC
address into the first entry field, and enter the address into the second entry field
for confirmation.
4. Click the Perform button to write the MAC address into the EEPROM.
5. Select the network status sheet print menu on the printer’s control panel, and print
the sheet. Check the MAC address printed on the sheet to see if it is correct. refer
to Figure 1-11 "Sample of Network Status Sheet".
Figure 5-10. MAC Address Setting Screen
C A U T I O N
 The MAC address required on the adjustment program is
written on the MAC address label on the Upper M/B Shield
Plate.
Make sure that the address written on the MAC address label
matches the MAC address settings in the EEPROM.
Figure 5-9. MAC Address Label
 Do not use the MAC address of the label attached to the
Wireless LAN Board since the address is not used for this
product.
Label, MAC address
the last six digits of MAC address
