Epson Artisan 730 Service Manual

Confidential
Revision Status
Revision Date of Issue Description
A July 29, 2009 First Release
B August 7, 2009 Revised Contents
 Chapter 4
 Caution of " Assembling the Printhead (p.135) " has been added.
 Chapter 5
 Made change in "5.1.1 Servicing Adjustment Item List (p.205) ".
 Made change in "5.3.1 PG Adjustment/PG Inspection (p.229) ".
C January 7,2010 Revised Contents
 Chapter 4
 Made change in " Assembling the Printhead (p.135) ".
D June 18, 2010 Revised Contents
 All chapters
 Description about Epson Artisan 835/725/Epson Stylus Photo PX820FWD/TX820FWD/PX720WD/TX720WD has
been added.
 Chapter 1
 Checkpoint has been added in "1.1 Features (p.15) ".
 Chapter 2
 Checkpoint has been added in "2.1 Overview (p.49) ".
 Made correction in "2.2 Power-On Sequence (p.53) ".
 Chapter 3
 Checkpoint has been added in "3.1 Overview (p.61) "
 Note has been added in "3-5 Check point for Fatal error according to each phenomenon (Printer Mechanism)
(p.65) ".
 Chapter 4
 Checkpoint has been added in "4.1 Overview (p.101) "
 Tool information for Epson Artisan 835/Epson Stylus Photo PX820FWD/TX820FWD has been added in "4.1.2
Tools (p.102) ".
 Checkpoint has been added in "4.1.4 Additional Procedure/Procedural Differences (p.104) ".
 Made change for checkpoint in "4.2 Disassembly Procedures (p.106) ".
 Checkpoint has been added in "4.2.3.1 ADF Unit (p.110) ".
 Checkpoint has been added in "4.2.3.5 Upper Housing (p.115) "
.

Epson Artisan 730 Specifications

General

Maximum Print Resolution	5760 x 1440 dpi
Maximum Photo Print Speed	4" x 6" photo in as fast as 10 seconds
ISO Print Speed Black	9.6 ISO ppm
ISO Print Speed Color	9.1 ISO ppm
Two-sided ISO Print Speed Black	4.9 ISO ppm
Two-sided ISO Print Speed Color	4.7 ISO ppm
Minimum Ink Droplet Size	1.5 picoliters
Maximum Copy Speed Black	39 cpm
Maximum Copy Speed Color	40 cpm
Maximum Copy Size	8.5" x 11"
Optical Resolution	2400 dpi
Maximum Resolution	9600 x 9600 dpi
Scanner Bit Depth	48-bit color in / 24-bit output
Wireless Connectivity	802.11 b/g/n
Ethernet	10/100
USB	Hi-Speed USB
PC-free Paper Support	Plain (8.5" x 11"), Photo (4" x 6", 5" x 7", 8" x 10", 8.5" x 11", 16:9 wide)
Input Paper Capacity	120 sheets plain paper, 10 envelopes
Output Paper Capacity	30 sheets
Operating Temperature	50 ° to 95 °F (10 ° to 35 °C)
Storage Temperature	-4 ° to 104 °F (-20 ° to 40 °C)
Operating Humidity	20 – 80% (no condensation)
Storage Humidity	5 – 85% (no condensation)
Rated Voltage	120 VAC
Rated Frequency	50 – 60 Hz
Rated Current	0.8 Amp
Power Consumption	Approx. 23 W ISO 24712, Approx. 4.5 W (Sleep Mode), Approx. 0.3 W (Power Off Mode)

Weight and Dimensions

Dimensions (W x D x H) Printing	17.6" x 25.8" x 5.9"
Dimensions (W x D x H) Storage	17.6" x 18.0" x 5.9"
Weight	21.2 lb
