Cable List
No. Connection
Connector pin
Quantity
Wire
Quantity
Connector pin
Quantity
Connection Note
1 AC Input Connector 3
−
Circuit protector,
FG
2
Circuit protector −
2
−
Noise filter
3 Noise filter
−
6
8
DPB
4 DPB
5
3
5
Switching
Power Supply (15V)
5 DPB
5
3
5
Switching
Power Supply (24V)
6 DPB
5
3
3
PC Power Supply
7 DPB
8
6
8
DMB
8 DPB
6
3
5
Regenerative
Control Board
9 DPB
8
6
8
ADMB *2
10
Switching
Power Supply (15V)
4
4
4
DMB
11
Switching
Power Supply (24V)
6
4
4
DPB
12 PC Power Supply
10
8
6,6,4,4
DMB, ADMB, HDD,
DVD drive
13
UPS Battery
Connector
3
2
3
ATX Power Supply
14
PC Power Supply
16,2
18 18
PCI-BPB
15
PC Power Supply
Relay Connector
4
8
4,4
HDD1，HDD2
16
DMB
80
80<F>
80
BPB
17
DPB
26
26<F>
25(D-SUB)
EMERGENCY
18 DMB
8
8 15(D-SUB)
Real-time I/O
Connector
19
CPU (
Standard)
9
8 4,10 DMB, FPB
20
CPU (
Standard)
10,12
7 10 PCI-BPB
