3. Pump socket (tank + pump) / Solenoid valve socket (town)
4. Serial port
5. Ethernet port
6. USB port
7. Barcode tracer port
Accessories
• Transport wedges to be kept
Use accessories
• Reflector
• Tube small diameter Ø 42 mm
• Tube large diameter Ø 53 mm
• Calibration grid
• 22 mm posiblock holder
• 18 × 14 mm Posiblock holder
• 22 mm stop
• 18 × 14 mm stop
• Unblocking clamp
• Ø 1.0 mm drill bit (mounted on the module) (optional)
• Ø 0.8 mm drill bit (optional)
• Ø 25 mm grooving wheel (mounted on the module)
• Chamfering wheel (mounted on the module)
• White felt tip marker
Maintenance accessories
• Orange dressing stone for glass roughing wheel
• White dressing stone for finishing wheel
• Square dressing stone for polishing wheel
• Open-ended spanners for tool changeover (quantity 2)
Options
• Trimaterial edger for chamfering glass lenses
• Barcode reader
• Barcode label roll
• Open or closed circuit spraying kit
Connection accessories
• Power cable
• RJ45 cable for the tracer-edger connection
• Wastewater evacuation pipe with attachment ring
2. INSTRUCTIONS FOR USE
In this section, you will find all the information concerning the following:
• The turning on (F p.12) andoff (F p.12) of the product
• The use of the touch screen and the keyboards (F p.12)
• The description of the main work screen (F p.15)
