Essilor Instruments DELTA

This chapter contains all the information relating to the product’s first use.
• Product description (F p.10)
• Using the device (F p.11)
1. DESCRIPTIVE DIAGRAMS
1. Trough
2. Centering blocking environment
3. Screen
4. Main switch
5. Connectors
6. Fan
7. Manufacturer plate
1. Power socket
2. Solenoid valve socket
Delta - Edging System > V1- 02-2020
10
USER MANUAL> II. FIRST STEPS WITH DELTA
