This chapter describes the maintenance procedures which you can perform on the tracer without the
intervention of a technician.
• Perform the diagnoses (F p.146)
• Checking and calibrating the tracer (F p.148)
• Test and calibrate the edger (F p.153)
• Consult the statistics and the technical history of the tracer (F p.155)
• Consult the statistics and the technical history of the edger (F p.160)
• Back up jobs and display configuration (F p.162)
• Changing or cleaning the blocking tube (F p.164)
• Change or clean the edger tools (F p.166)
• Maintain and clean the tracer-centerer-blocker (F p.171)
• Maintaining and cleaning the edger (F p.171)
1. PERFORM THE AUTOTEST OF THE TRACER
This menu allows you to perform a self-diagnosis of the functions of the tracer.
Select > > from the work screen.
1. Camera test
2. LED band tests
3. Principal LED test
There exist two types of diagnosis:
• Diagnoses carried out with reflectors: test camera and main LED
• Diagnoses carried out without reflectors: LED band test
