• Always use the tools recommended by Essilor.
• Never use the edger if one of the tools is missing. Never remove a used or broken tool if you
cannot replace it.
• All tools coming into contact with the module must be clean and dry in order to prevent water
from seeping into the mechanisms.
• The use of broken tools may cause lens breakage or errors with respect to lens shape or drill-
hole diameter: change the tools as soon as they are worn (check the indicators and statistics of
your digital system).
• Incorrect positioning of the tools may cause breakage or errors with respect to lens shape or
drill-hole diameter: insert the tools fully.
a. Changing or cleaning the drill bit
The wear indicator informs you of the need to change the 0.8 mm drill bit after 250 holes and the 1.0 mm bit
after 500 holes.
Have the following to hand:
• Open-ended spanner
• The drill bit to be replaced
From the working screen of your edger, select > > > to change or clean the drill
bit.
You can access the tool-change menu by pressing on the work screen.
Select the drill bit diameter to install (0.8 mm or 1.0 mm).
For cleaning, select the drill bit diameter in place.
Select the type of operation:
• Installing a new drill bit: at the end of the procedure, the wear statistics will be reset to
zero.
• Replace the drill bit with a different diameter bit or clean the bit in place: the wear statistics
will not be reset.
