Press to loosen the clamps and remove the plastic pattern, then to return to the work screen.
The calibration cycle is complete.
Press if the feeler position is not correct.
A message is displayed indicating that calibration by a technician is required: contact your technical
department.
b. Calibrate the touch screen
Calibrate the touch screen if your operations have become difficult due to lack of precision.
Touch screen malfunction
You can directly access the calibration screen without using the settings menu. To do this, press on the
edging screen for 5 seconds.
Calibrate the touch screen
Select > > from the work screen.
A confirmation message is displayed:
• Press to start calibration.
• Press to cancel and return to the menu
Point precisely on each cross as they are displayed, holding the stylus perpendicular to the screen so as
not to alter the calibration.
The settings menu is displayed automatically once the calibration is finished.
Press to return to the work screen.
5. STATISTICS AND TECHNICAL HISTORY OF THE TRACER
This menu enables you to visualize the number of cycles carried out by the tracer-centerer-blocker. It also
gives you access to the technical history.
• Tracer-centerer-blocker statistics (F p.156)
• Technical history log and errors (F p.158)
