• Environment (F p.178)
• General features (F p.178)
• “Tracer centering device blocker” function (F p.179)
• “Edger” function (F p.180)
1. ENVIRONMENT
To install your digital machine and to profit from its utmost precision, it is necessary that you have a stable
work surface, isolated from shocks and oscillations, perfectly horizontal and at a proper height
(approximately 70 cm).
The temperature and the humidity of the room where you use your machine must be within the following
ranges of values:
Operation:
• Temperature between +10 °C and +40 °C
• Humidity: between 30% and 75%
Storage:
• Temperature between -+5°C and +50°C
• Humidity: between 25% and 95%
Altitude: < 2,000 m
Degree of pollution: 2
Avoid sudden changes in temperature and humidity and install your system:
• in an area not directly exposed to sunlight
• away from all heat sources
• away from all strong magnetic fields
• away from all chemical products, corrosive vapours and liquids
Take care not to block the vents and to leave enough space above the device. Do not place any object on the
device. Avoid exposing the device to vibrations or shocks.
The back of your machine must be at least 20 cm away from a wall.
2. GENERAL FEATURES
• Networking possibility:
◦ PC
◦ Essibox
• RS232C and RJ45 ports
• Integrated auto-maintenance functions (self-calibration, autotests)
• Dimensions: L 550, D 500, H 580 mm
• Size of colour touch screen: 8.4 inches
• Weight: 57 kg
• Power supply: 220-240V – 50/60 Hz or 100-120V – 50/60 Hz
• Power consumption: 1350 W – 10 A for 230 V and 15 A for 115 V
