9. Front surface chamfering
◦ Small chamfer
◦ Large chamfer
◦ No chamfering
10. Rear surface chamfering
◦ Small chamfer
◦ Large chamfer
◦ No chamfering
11. Manual lens clamping
Press and hold to close the lens clamp shafts manually.
12. Start the edging cycle
The door closing and lens clamping are automatic.
Always browse from left to right: depending on your selection, certain menus will be available while
others will not.
Your habits taken into account
The edger memorises your working habits: as time goes by, the buttons of the functions you use most
often will be displayed by default.
b. Calling up a shape
There are 3 ways of calling up the shape you want to edge:
• Calling the current shape:
> Press to display the shape being processed on the tracer.
• Calling up the number of a shape saved on the tracer:
> Press for a few seconds to open the numeric keypad.
> You can then call a shape by the ID which was allotted to it.
• Job call via a barcode:
> scan the barcode using the barcode reader (optional).
> Press to continue and display the job on the edger. The modifications underway are then ignored.
> Press to prevent the display of the job and finish the modifications underway on the tracer.
A reminder of the type of posiblock required is displayed on the shape. It is crucial to use the proper
accessory to edge the lens. Otherwise, an error message is displayed at the start of the cycle.
