This chapter describes the procedure for the positioning of drilling points (drill-holes, slots, notches) on a
lens.
• Description of the drilling screen (F p.82)
• Configuring drilling settings (F p.85)
• Drilling models (F p.90)
Once the drilling parameters have been set, you can go on to the centering of the lens.
Prerequisite: you must already have carried out lens tracing.
Pre-existent drillings
If you trace a demo lens or a pattern and if drill-holes are detected, then the drilling screen is
automatically displayed once the tracing is carried out.
Glass lenses
The drilling function is not available for glass lenses.
1. LEGEND SCREEN
The drilling screen is accessible:
• from the centering screen,
• from the edging preparation screen.
Press to prepare a drilled job.
