The following screen is displayed:
1. Work area
Colors which may appear on screen:
◦ (green) Current shape (from the traced shape) and associated drilling points
◦ (cyan) Current shape (obtained by symmetry with the traced shape) and associated drilling
points
◦ (yellow) Limit of the no-drill area
◦ (orange) Nasal or temporal side indicator
◦ (red) Selected drilling point
◦ (blue) Reference drilling point (by default, the first one created on each side – nasal and
temporal)
◦ A drilling point with a color infill indicates non through-drilling
Curve angle
Binocular view
2. Active eye
The selected eye has an orange frame around it.
3. Type of drilling
◦ Drill-hole
◦ Slot
◦ Notch
