b. Connection with a PHI tracer
1. Metal frame - acquisition of the groove profile
2. Plastic frame
3. Local tracing (not used here)
4. Selection right eye/left eye
5. Cycle start-up button
Perform tracing according to the type of selected frame.
Click on the cycle start-up button.
A beep rings out.
The form appears directly on the work screen of the product.
The form arrives directly on the Delta 2 work screen, therefore it’s not possible to recall a
previous shape..
>
>
1
2
Delta - Edging System > V1- 02-2020
36
USER MANUAL> III. CARRY OUT AN OPTICAL TRACING
