d. Check the optical system
1. Light panel luminosity adjustment
2. Camera contrast adjustment
3. Screen brightness adjustment
4. TEST AND CALIBRATE THE EDGER
If you notice deviations in the job, or encounter difficulties while using the touch screen,
You can:
• An inspection of the position calibration for the feeler in the trough, (F p.153)
• A Calibration of the touch screen (F p.155).
If the edger detects a variation, an adjustment is carried out during the cycle.
a. Control the calibration of the monofeeler
If the beveling or chamfering are misaligned, the edger may need to be recalibrated.
You can perform a calibration inspection of the position of the monofeeler in the trough.
