d. Work screens
Work screen (tracer)
1. Icon for accessing the edger’s work screen
2. Job information
3. Icon to access machine settings
4. Connected devices
5. Active eye and information on the shape
6. Work area
7. Tracer-centerer-blocker icon
8. Call from the Tess tracer (optional)
9. Actions available on the present screen
For more information, consult the section performing an optical tracing > tracing environment >
captioned screen. (F p.20)
