• Lens material
LENS MATERIAL AVAILABLE OPTIONS
The quality of the chamfer depends on the spraying. Make
sure there is a constant flow of water until the end of the
chamfering operation.
The chamfering wheel supplied cannot be used on glass
lenses. For further information, contact your technical
department.
• Thickness at the edge of the lens
LENS THICKNESS AVAILABLE OPTIONS
> 1.2 mm
Between 1 and 1.2 mm
< 1 mm
• Distance between the edge of the groove and the edge of the lens
DISTANCE AVAILABLE OPTIONS
> 0.8 mm
Between 0.5 and 0.8 mm
< 0.5 mm
The chamfers available also depend on the lens shape and the posiblock used when blocking.
Press on the buttons and to configure a small chamfer, a large chamfer or no chamfer on the
front and rear surfaces of the lens.
