Essilor Instruments DELTA User Manual

Input the wrap angle and the frame base.
Press the button.
The following screen is displayed:
Select the wrap angle value to modify it.
The value is displayed in red.
Place the frame on the screen:
• The vertical blue line must be in the center of the frame
• The bridge of the frame superimposed on the base line.
Use the and buttons to align the light blue lines with the nasal and temporal ends of the rims.
>
>
1
2
3
4
Delta - Edging System > V1- 02-2020
32
USER MANUAL> III. CARRY OUT AN OPTICAL TRACING
