MB1 User Manual
© 2016 Expert Electronics
FRONT PANEL DESCRIPTION
M.RD - Button to recall the saved frequency from the memory.
Press the M.RD button to tune on the saved frequency.
MD - Button to switch modulation type Down the list.
Press the MD button to select the previous modulation type Down the list.
Press again to cycle through the modulation types.
MU - Button to switch modulation type Up the list.
Press the MU button to select the next modulation type Up the list.
Press again to cycle through the modulation types.
FD - Button to Reduce the band width of the receiver filter.
Press the FD button to select a narrower receiver band filter from the predefined set.
Press again to cycle through the filters.
FU - Button to Increase the band width of the receiver filter.
Press the FU button to select a wider receiver band filter from the predefined set.
Press again to cycle through the filters.
18) NR - Button to enable Noise Reduction.
Press the NR button to enable noise reduction of the receiver (more details in DSP functions
using ).
NB1 - The First Noise Blanker button for impulse interference.
Press NB1 button to enable the first noise blanker for impulse interference.
NB2 - The Second Noise Blanker button for impulse interference.
Press NB2 button to enable the second noise blanker for impulse interference.
Note:
( The NB1 and NB2 algorithms are different. Try each of them to reach the best impulse
interference reduction.
( NB1 and NB2 Noise Blankers can also be used simultaneously.
164
