MB1 User Manual

FRONT PANEL DESCRIPTION

IQ - IQ-files record button.

Press the IQ button to record the whole bandwidth to file.

Record is mode indicated in the Main window (more details in IQ-files recording ).

Attention!

Continuous recording of IQ-files, could lead to using all available free disk space

on your PC!

XVTR - Transverter mode button.

Short press the XVTR button to enable transverter mode.

Press and hold the XVTR button to open the transverter mode local settings panel.

Note:

(

Transverter mode is not yet supported by the current version of the software. We plan to add

it in new versions of the software.

STEP - Button to change the step of frequency shifting.

Press the STEP button to select the required step of frequency shifting. The current step size

is displayed in the Main window.

In Auto mode, the transceiver will change the step size of its frequency shifting dependent

on the speed used when tuning the knobs (more details in Frequency Tuning STEP

Changing ).

Z+ - Zoom in panorama.

Press Z+ to zoom in the transceiver's panorama (more details in ZOOM-In ZOOM-Out the

graphics ).

Note:

(

Zoom in of the panorama is carried out relative to the blue triangle - zoom center marker.

Z- - Zoom out panorama.

Press Z- to zoom out the transceiver's panorama (more details in ZOOM-In ZOOM-Out the

graphics ).

Note:

(

Zoom out of the panorama is carried out relative to the blue triangle - zoom center marker.
