MB1 User Manual

MAIN SCREEN DESCRIPTION

· XIT On/Off – enable/disable XIT offset.

· XIT Reset - reset XIT offset to 0.

· Split – enable/disable Split mode.

· TX/Play – turn to TX and play the signal record in air.

· Voice recording – enable/disable voice recording.

· RX ANT - enable/disable receive antenna.

· LOCK - lock the frequency tuning.

· A>B - assign the frequency from heterodyne VFO A to heterodyne VFO B.

· B>A - assign the frequency from heterodyne VFO B to heterodyne VFO A.

· B<>A - frequency exchange between VFO A and VFO B.

For the knobs - available the following functions:

· Unused – encoder is unused.

· Volume – volume adjustment.

· Mic Gain – Mic gain adjustment.

· SQL – squelch threshold adjustment.

· Filter Low/High – tuning the frequency of the low/high filter's front.

· Filter Width – adjusting the filter width.

· Filter Shift - shifting the filter's central frequency.

· Drive – adjusting the output power.

· IF – tuning the frequency by moving the filter over the panorama.

· RF Gain – RF Gain control.

· CW Speed – CW Speed control.

· RIT Offset – adjusting the RIT Offset.

· XIT Offset – adjusting the XIT Offset.

In the right part of the menu you can see the main panel settings:

· Enable - enable E-Coder panel control.

· Use IF - frequency tuning by moving the filter over the panorama.

· Use IF as RIT - tuning by IF when the RIT offset is on.

· Use IF as XIT - tuning by IF when the XIT offset is on.

· VFO B - enable sub-receiver.

· Key Led - enable backlit keypad.
